Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP
UniFi WAN Switch RJ45 for UniFi networks, featuring 1 GbE RJ45 ports, 3 10 GbE RJ45 ports, and 20 Gbps switching capacity.
Ubiquiti
Ubiquiti Inc offers a broad and expanding portfolio of networking products and solutions for service providers and enterprises. Their service provider product platforms provide carrier-class network infrastructure for fixed wireless broadband, wireless backhaul systems and routing. Their enterprise product platforms provide wireless LAN infrastructure, video surveillance products, switching and routing solutions and machine-to-machine communication components. Ubiquiti Networks believes that their products are highly differentiated due to proprietary software protocol innovation, firmware expertise, and hardware design capabilities.
Share this product:
Ubiquiti USW-WAN-RJ45 UniFi WAN Switch RJ45
USW-WAN-RJ45 is a UniFi switch for managed business networks, with 1 GbE RJ45 ports, 3 10 GbE RJ45 ports, 20 Gbps switching capacity.
Key Features
- 10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
- High-density switching with 1 GbE RJ45 ports, 3 10 GbE RJ45 ports.
- Performance designed for demanding UniFi networks, including 20 Gbps switching capacity.
- Rack mount (1U) form factor for clean installation in network cabinets or branches.
- Managed with Version 9.1.120 and later for centralised UniFi monitoring and control.
Technical Specifications
- Dimensions: 442.4 x 120 x 43.7 mm
- Weight: Without mounting brackets: 2.3 kg; With mounting brackets: 2.4 kg
- Connectivity: 1 GbE RJ45 ports, 3 10 GbE RJ45 ports
- Power method: (2) Universal input, 100–240V AC, 50/60 Hz
- Max. power consumption: 18W
- Switching capacity: 20 Gbps
- Total non-blocking throughput: 10 Gbps
- Forwarding rate: 15 Mpps
- Form factor / mounting: Rack mount (1U)
- Operating temperature: -5 to 40° C
- Operating humidity: 10 to 90% noncondensing
- Certifications: CE, FCC, IC, Anatel: 04273-25-08356
- Application requirements: Version 9.1.120 and later
- Redundancy: (2) AC inputs
