Ubiquiti UA-Hub-Door-Mini UniFi Access Mini Hub Single Door

https://citytechnology.com.au/web/image/product.template/22383/image_1920?unique=7ca874f

Product Code: UA-Hub-Door-Mini

$ 241.45 incl. GST 241.45000000000002 AUD $ 241.45

$ 209.00

    This combination does not exist.

    Add to Cart Buy Now
    Ubiquiti
    Ubiquiti

    Ubiquiti Inc offers a broad and expanding portfolio of networking products and solutions for service providers and enterprises. Their service provider product platforms provide carrier-class network infrastructure for fixed wireless broadband, wireless backhaul systems and routing. Their enterprise product platforms provide wireless LAN infrastructure, video surveillance products, switching and routing solutions and machine-to-machine communication components. Ubiquiti Networks believes that their products are highly differentiated due to proprietary software protocol innovation, firmware expertise, and hardware design capabilities.

    Share this product:

    Ubiquiti UA-Hub-Door-Mini UniFi Access Mini Hub Single Door

    Product Code: UA-Hub-Door-Mini

    The UniFi Access Hub Mini is a Compact Access Control Hub for a single door.

    (1) Lock terminal (12V and Dry switchable)

    (2) Additional inputs (sensor and button)

    Connect and power via PoE++

    Connect up to two UniFi Access Readers or Protect Cameras


    Mechanical
    Dimensions113 x 66 x 27.6 mm (4.4 x 2.6 x 1.1")
    Weight190 g (6.7 oz)
    Enclosure materialPolycarbonate, metal
    Hardware
    Networking interface(3) GbE RJ45 ports
    Power methodPoE++
    Max. power consumptionWithout PoE output: 19W
    With PoE output: 50W
    PoE input50V DC, 1A
    PoE output(2) PoE ports, total 31W
    Button(1) Factory-reset
    (1) Dry/Wet switch
    Digital inputRequest to exit/door position sensor
    Output relayDry: 30V DC, 1A
    Wet: 12V DC, 1A
    Recommend max. cable length
    18 AWG
    UACC-Cable-DoorLockRelay length    		20
    AWG length    		22
    AWG length    		24
    AWG length
    UA-Lock-Electric
    (400mA)    		100 m
    (328 ft)    		66 m
    (217 ft)    		42 m
    (138 ft)    		25 m
    (82 ft)
    UA-Lock-Magnetic-270kg
    (800mA)    		46 m
    (151 ft)    		30 m
    (98 ft)    		20 m
    (66 ft)    		12 m
    (29 ft)
    UA-Lock-Magnetic-540kg
    (500mA)    		80 m
    (262 ft)    		51 m
    (167 ft)    		32 m
    (105 ft)    		20 m
    (66 ft)
    Other locks
    (1A)    		36 m
    (118 ft)    		24 m
    (79 ft)    		15 m
    (49 ft)    		9 m
    (30 ft)
    PoE cabling requirementsCable 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
    The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
    Operating environmentIndoor use only
    Ambient operating temperature-10 to 40° C (14 to 104° F)
    Ambient operating humidity5 to 90% noncondensing
    Software informationThe software version of a product can be checked at https://unifi.ui.com
    CertificationsCE, FCC, IC
    Document number, and issue date and/or revision levelUA-Hub-Door-Mini, V01
    Software
    Management applicationUniFi Access: Version 2.5.2 and later
    LEDs
    PoE inSystem status
    PoE outWire status/activity
    Input/output relayWire status/activity



    Mechanical
    Dimensions113 x 66 x 27.6 mm (4.4 x 2.6 x 1.1")
    Weight190 g (6.7 oz)
    Enclosure materialPolycarbonate, metal
    Hardware
    Networking interface(3) GbE RJ45 ports
    Power methodPoE++
    Max. power consumptionWithout PoE output: 19W
    With PoE output: 50W
    PoE input50V DC, 1A
    PoE output(2) PoE ports, total 31W
    Button(1) Factory-reset
    (1) Dry/Wet switch
    Digital inputRequest to exit/door position sensor
    Output relayDry: 30V DC, 1A
    Wet: 12V DC, 1A
    Recommend max. cable length
    18 AWG
    UACC-Cable-DoorLockRelay length    		20
    AWG length    		22
    AWG length    		24
    AWG length
    UA-Lock-Electric
    (400mA)    		100 m
    (328 ft)    		66 m
    (217 ft)    		42 m
    (138 ft)    		25 m
    (82 ft)
    UA-Lock-Magnetic-270kg
    (800mA)    		46 m
    (151 ft)    		30 m
    (98 ft)    		20 m
    (66 ft)    		12 m
    (29 ft)
    UA-Lock-Magnetic-540kg
    (500mA)    		80 m
    (262 ft)    		51 m
    (167 ft)    		32 m
    (105 ft)    		20 m
    (66 ft)
    Other locks
    (1A)    		36 m
    (118 ft)    		24 m
    (79 ft)    		15 m
    (49 ft)    		9 m
    (30 ft)
    PoE cabling requirementsCable 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
    The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
    Operating environmentIndoor use only
    Ambient operating temperature-10 to 40° C (14 to 104° F)
    Ambient operating humidity5 to 90% noncondensing
    Software informationThe software version of a product can be checked at https://unifi.ui.com
    CertificationsCE, FCC, IC
    Document number, and issue date and/or revision levelUA-Hub-Door-Mini, V01
    Software
    Management applicationUniFi Access: Version 2.5.2 and later
    LEDs
    PoE inSystem status
    PoE outWire status/activity
    Input/output relayWire status/activity
