Tycon Power TP-DCDC-4848G-HP 36-72VDC IN 56VDC OUT, 50W DC to DC Converter


Product Code: TP-DCDC-4848G-HP

Barcode: 1PTP-DCDC-4848G-HP

140.80 incl. GST 140.8 AUD 140.80


    This combination does not exist.

    Add to Cart Buy Now

    Tycon Power
    Tycon Power

    Tycon Power Systems designs and manufactures turnkey remote power systems utilizing solar and wind power and accessories including a variety of unique PoE and power conversion products. Tycon Power® products include; industrial strength outdoor PoE switches, midspan power inserters, PoE surge protection, DC to DC converters, and a large selection of accessories.

    Share this product:

    Tycon Power TP-DCDC-4848G-HP 36-72VDC IN 56VDC OUT, 50W DC to DC Converter

    The TP-DCDC-4848G-HP DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a +/-48V battery system.

    The Tycon Power TP-DCDC-4848G-H have an integrated Gigabit Passive PoE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 36VDC and 72VDC.

    Tycon Power TP-DCDC-4848G-H accepts data-in to a shielded RJ45 Jack and provide data-out and PoE power on the shielded RJ45 output jack.

    They work by supplying power on the Ethernet pins 4,5(V+) and 7,8(V-).

    Tycon Power have various protections for surge, short circuit and overload. The units have power output of 50W.

    Tycon Power TP-DCDC-4848G-HP Features:

    • Input Voltage +/- 36-72VDC; Output 48VDC Passive PoE
    • Integrated Gigabit PoE Inserter
    • High Power 50W
    • Short Circuit, Over Current and Over Voltage Protection
    • High Temperature Operation 60°C

    Dimensions: 85 x 76 x 36mm

    Weight: 134g
