PolyPhaser DGXZ+36NMNF-A 800-2500MHz BROADBAND, DC pass

https://streakwave.com.au/web/image/product.template/5268/image_1920?unique=91e279a

Product Code: DGXZ+36NMNF-A

299.20 incl. GST 299.2 AUD 299.20

259.00


    This combination does not exist.

    Add to Cart Buy Now

    PolyPhaser
    PolyPhaser

    PolyPhaser leads the market with its patented RF protection solutions, specifically supporting communications systems. Based on its extensive experience with multi-stage surge protection, PolyPhaser continuously expands its product offering to support the needs of advanced applications with technologies such as DC Block, DC Pass and Ultra Low PIM.


    Share this product:

    PolyPhaser DGXZ+36NMNF-A 800-2500MHz BROADBAND, DC pass


    Product Code: DGXZ+36NMNF-A

    Specifications:

    • Impedance: 50 Ohm

    • Connector In Series: N

    • Connector In Gender: Male

    • Connector Out Series: N

    • Connector Out Gender: Female

    • Minimum Frequency: 800 MHz

    • Maximum Frequency: 2.5 GHz

    • Maximum Input Power: 300 Watts

    • Direction: Directional

    • Throughput Energy: 1,500 uJ

    Description:

    Type N M/F Coaxial RF Surge Protector, 800MHz - 2.5GHz, 300W, IP67, 36 V Max., 1.5mJ, 20kA, Hybrid, Bracket Down, Hole Mount

    PolyPhaser coaxial RF surge protector (also known as lightning surge protector, lightning surge arrestor or suppressor) DGXZ+36NMNF-A is in-stock and will ship same-day as purchased. This radio frequency surge protector / lightning surge arrestor helps protect your equipment from electromagnetic pulse (EMP) or power surges that are commonly caused by lightning or other strong electrical changes. Our radio frequency coaxial surge protector product is commonly used for radio and antenna installations where part or all system equipment is outdoors to protect sensitive equipment and is designed to pass 800 MHz to 2.5 GHz while suppressing DC surge.


    While this radio frequency lightning surge suppressor operates in a range of frequencies from 800MHz to 2.5GHz, it is supporting a power handling maximum of 300 Watts. RF surge protector DGXZ+36NMNF-A from PolyPhaser incorporates hybrid technology to provide protection for equipment at up to the max. power of 300W. Our coax surge protection device for RF is manufactured with a type N connection in and a N type out.


    DGXZ+36NMNF-A is constructed with a male gender for the input and female for the output. This M/F type N to N type surge protecting component for RF has a let-through energy of 1.5mJ. The coaxial lightning surge arrestor is IP rated, it has an IP67 rating.


    PolyPhaser provides one of the largest varieties of RF / microwave surge protector devices available for same-day shipping. Our facilities ship type N M/F coaxial RF surge protector, 800MHz - 2.5GHz, 300W, IP67, 36 V max., 1.5mJ, 20kA, hybrid, bracket down, hole mount as well as the rest of our surge protection product line from in-stock inventory the same day as purchased. We support our customers with a sense of urgency while providing innovative lightning and surge protection solutions that ensure reliable operation of critical systems for a connected world.
